Name: Krome EX
Brand: Korg
SKU: KROME-61EX
Price: 699.0 GBP
Availability: OutOfStock

Question 1

Specifications

Accepted Answer

Keyboard

KROME EX-61: Semi Weighted Keyboard. Velocity sensitive is supported, after touch is not supported.
Standard C2 - C7 (transposable in the range [C1...C6]-[C3...C8])

System

EDS-X（Enhanced Definition Synthesis - eXpanded）

Sounds

Maximum Polyphony: 120 voices (120 Oscillators) / Single Mode, 60 voices (120 Oscillators) / Double Mode
*The maximum simultaneous voice polyphony will vary depending on oscillator settings, velocity crossfading and whether you are using mono or stereo multi samples.

PCM Memory: 4 GB (In case of 48 kHz, 16-bit Linear PCM converted)
728 multi samples (including 44 Stereo multi-samples)
2,502 drum samples (including 574 Stereo Drum samples )

Program

Oscillator: OSC1 (Single); OSC1 + 2 (Double): Stereo multi samples are supported 8 velocity zones per oscillator with switching, crossfades and layers

Filters: Four types of filter routing (single, serial, parallel, 24 dB). Two multi-mode filters per oscillator (low pass, high pass, band pass, band reject)

Driver: Per-voice nonlinear driver and low boost

EQ: Three bands, with sweepable mid

Modulation: For each oscillator, two envelope generators (Filter & Amp), two LFOs, two key tracking generators (Filter & Amp), two AMS mixers, Pitch EG, Common LFO, two common key tracking generators

Combination

Timbre Number: Max 16. For each Timbre, keyboard and velocity split/layer/crossfades.
Modifications to the program settings via the Tone Adjust function.

Drum Kit: Stereo and mono drum samples. 8 velocity zones switch (crossfades and layers)

The number of Combination / Program / Drum Kit

User Combination: 768 Combination (512 Preload)

User Program: 1536 Program (896 Preload)

User Drum Kit: 80 Drum Kit (48 Preload)

Preset Program: 256 GM2 Program + 9 GM2 Drums Program

Effects

Insert Effects: 5 Insert Effects (stereo in/out)

Master Effects: 2 Master Effects (stereo in/out)

Total Effect: 1 Total Effect (stereo in/out)

Timbre / Track EQ: 3-band EQ per in 1 Timbre / in 1 Track

Effect Types: 193 types (Usable as insert, master, or total effects. However, double-size effects cannot be used as a total effect.)

Modulation: Dynamic Modulation, 2 Common LFO

Effects Control Busses: Stereo side chain (Limiter, Gate, Vocoder etc.)

Effect Preset: 32 preset per effect

Polyphonic Arpeggiator

Program Mode: 1 unit

Combination, Sequencer Mode: 2 units are available

Number of pattern: 5 preset Arpeggio pattern, 1,088 User Arpeggio pattern (960 Preload)

Drum Track

Preset Patterns: 710 patterns (Common with the preset pattern of the Sequencer mode)

User Patterns: 1,000 patterns (Pattern created in Sequencer mode can be converted to drum track user pattern)

Others: Configurable “Trigger Mode / Sync / Zone”

Sequencer

Tracks: 16-track + 1 master track

Number of Songs: 128 Songs

Resolution: ♩=1／480

Tempo: 40.00 - 300.00 (1/100 BPM resolution)

Maximum memory: 210,000 MIDI events

Template Songs: 16 preset / 16 user template songs

Cue List function: 20 Cue List
Songs can be arranged consecutively or repeatedly in up to 99 steps, a cue list can be converted back into a song.

Pattern / RPPR (Realtime Pattern Play and Recording): 710 Preset / 100 User pattern (Per song). 1 pattern set per song

Format: KORG (KROME) format, SMF format 0 and 1

Media

Load, Save, Utility, Data filer functionality (Save and Load MIDI System Exclusive Data)

Controllers

Controllers: Joystick, SW [1], SW [2]

Realtime Control: [SELECT] Switch: TONE, USER, ARP

4 Knobs: Modulation, User, Arpeggio control

Drum Track: [DRUM TRACK] Switch: On/Off

Arpeggiator: [ARP] Switch: On/Off

User Interface

Display: Touch view graphical User Interface, 7 -inch Color TFT LCD, 800 x 480 pixel, Onboard LCD brightness control

Mode Switches: [COMBI], [PROG], [SEQ], [GLOBAL], [MEDIA] Switch

VALUE controllers: [VALUE] Dial, [INC], [DEC] Switches, 10 key block ([0] - [9], [-], [.], [ENTER], [COMPARE])

BANK Switches: [A], [B], [C], [D], [E], [F] switches (in Combination mode, [A], [B], [C], [D] switches are available)

SEQUENCER switches: [PAUSE]、[REW]、[FF]、[LOCATE]、[REC]、[START／STOP]

TEMPO: TEMPO

Others: [PAGE] switch, [WRITE] switch, [EXIT] switch, [VOLUME] knob, Contrast knob

Outputs

AUDIO OUTPUT, L／MONO, R: 6.3mm (Mono) Phone jack, Unbalanced.
Output Impedance: 1.1[kΩ] (L / Mono terminal: in case of Mono output, = 550[Ω]).
Maximum level: +16.0 [dBu], Load Impedance: more than 10 [kΩ].

Headphone Output: 3.5mmStereo phone jack.
Output Impedance: 33[Ω].
Maximum level: 60 + 60 [mW] (In case of 33[Ω] Loaded)

Control Input

DAMPER (Half Damper supported), ASSIGNABLE SWITCH, ASSIGNABLE PEDAL

Others

MIDI: IN, OUT

USB: USB-MIDI Interface (TYPE B) x 1

SD Card Slot: Max 2 GB / SD Memory Card is supported
Max: 32 GB/ SDHC Memory Card is supported (SDXC Memory Card is not supported)

Principle Specifications

Power: Power supply (DC12V 3.5A), POWER switch

Power Consumption: 13W

Dimensions (W x D x H):: KROME EX-61: 1,027 mm × 313 mm × 93 mm / 40.43 x 12.32 x 3.66 inches
KROME EX-73: 1,191 mm × 313 mm × 93 mm / 46.89 x 12.32 x 3.66 inches
KROME EX-88: 1,448 mm × 383 mm × 131 mm / 57.01 x 15.08 x 5.16 inches

Weight: KROME EX-61: 7.2 kg / 15.87 lbs.
KROME EX-73: 8.2kg / 18.08 lbs.
KROME EX-88: 14.7kg / 32.41 lbs.

Included Items: AC Adapter,

Accessories (sold separately)

Keyboard stand: Standard-S-ABK (for 61 key model)
Standard-M-SV (for 73 key model)
Standard-L-SV、L-ABK (for 88 key model)

Soft shell cases: SC-KINGKORG/KROME (for 61 key model)
SC-KROME 73 (for 73 key model)
SC-KROSS2 88/KROME 88 (for 88 key model)

Expression/volume pedal: XVP-20

Foot controller: EXP-2

Damper pedal: DS-1H

Pedal switch: PS-1
PS-3

*	All product, company, and standard names are trademarks or registered trademarks of their respective holders.
*	Appearance and specifications of products are subject to change without notice.

Question 2

Warranty

Accepted Answer

All new products are sold with a 2-year manufacturer warranty which is upgraded to 3 years when bought direct from Korg UK.

Certified Refurbished products also come with a one year warranty.

Warranty policy

Question 3

Returns

Accepted Answer

We offer a 30-day returns period on all products purchased directly from Korg UK.

Return policy.
